MySQL中dd::columns表结构转Table过程以及应用
一、中转MySQL的结构及dd表介绍
MySQL的dd表是用来存放表结构和各种建表信息的，客户端建的过程表都存在mysql.table和mysql.columns表里，还有一个表mysql.column_type_elements比较特殊，中转用来存放SET和ENUM类型的结构及字段集合值信息。看一下下面这张表的过程mysql.columns表和mysql.column_type_elements信息。为了缩短显示长度，中转这里只展示几个重要的结构及值。
复制#建表：
mysql.columns表说明如下：
ordinal_position是该字段在表里的偏移量，这里多了3个字段，中转DB_ROLL_PTR、结构及DB_TRX_ID、过程id是中转用来执行undo的，记录了字段的结构及版本信息。
default_value_utf8是过程用来保存默认值的。options里面有interval_count用来保存集合类型的数值数的。columns表的云服务器options的key一共有如下几种：
复制static const std::set<String_type> default_valid_option_keys = { "column_format", "geom_type", "interval_count", "not_secondary", "storage", "treat_bit_as_char", "zip_dict_id", "is_array"};1.2.3. 复制mysql> select * from mysql.column_type_elements where column_id=4286;+-----------+---------------+------+| column_id | element_index | name |+-----------+---------------+------+| 4286 | 1 | x || 4286 | 2 | y |+-----------+---------------+------+2 rows in set (0.01 sec)#这里的column_id=4286是col4的id值，x和y分别对应了set定义时候的2个集合值。1.2.3.4.5.6.7.8.9. 二、代码跟踪现在重新启动数据库，跟踪一下这个columns表怎么转为代码里面的TABLE的field对象。首先找到表的dd信息然后打开表获取field信息。
复制mysql> select * from t1;1.输入该命令后找到columns表转为field的代码：
复制#0 fill_column_from_dd ( thd=0x555558b35a06 <std::char_traits<char>::compare(char const*, char const*, unsigned long)+61>, share=0x7fffe83f1b60, col_obj=0x555558bb0a5e <std::__cxx11::basic_string<char, std::char_traits<char>, Stateless_allocator<char, dd::String_type_alloc, My_free_functor> >::compare(std::__cxx11::basic_string<char, std::char_traits<char>, Stateless_allocator<char, dd::String_type_alloc, My_free_functor> > const&) const+142>, null_pos=0x7fffe83f1880 "\005", null_bit_pos=32767, rec_pos=0x7fff2c05ac10 "explicit_encryption", field_nr=0) at /mysql/sql/dd_table_share.cc:955#1 0x00005555593c4c17 in fill_columns_from_dd (thd=0x7fff2c006890, share=0x7fff2cbf19e8, tab_obj=0x7fff2cbb9b38) at /mysql/sql/dd_table_share.cc:1235#2 0x00005555593c9e54 in open_table_def (thd=0x7fff2c006890, share=0x7fff2cbf19e8, table_def=...) at /mysql/sql/dd_table_share.cc:2408#3 0x0000555558e76a13 in get_table_share (thd=0x7fff2c006890, db=0x7fff2cbeeff0 "db1", table_name=0x7fff2cc03210 "t1", key=0x7fff2cbeed87 "db1", key_length=7, open_view=true, open_secondary=false) at /mysql/sql/sql_base.cc:801#4 0x0000555558e76f08 in get_table_share_with_discover (thd=0x7fff2c006890, table_list=0x7fff2cbee9b8, key=0x7fff2cbeed87 "db1", key_length=7, open_secondary=false, error=0x7fffe83f1ea4) at /mysql/sql/sql_base.cc:889#5 0x0000555558e7cd34 in open_table (thd=0x7fff2c006890, table_list=0x7fff2cbee9b8, ot_ctx=0x7fffe83f2380) at /mysql/sql/sql_base.cc:3230#6 0x0000555558e81769 in open_and_process_table (thd=0x7fff2c006890, lex=0x7fff2c01bdf0, tables=0x7fff2cbee9b8, counter=0x7fff2c01be48, prelocking_strategy=0x7fffe83f2408, has_prelocking_list=false, ot_ctx=0x7fffe83f2380) at /mysql/sql/sql_base.cc:5118#7 0x0000555558e833bd in open_tables (thd=0x7fff2c006890, start=0x7fffe83f23f0, counter=0x7fff2c01be48, flags=0, prelocking_strategy=0x7fffe83f2408) at /mysql/sql/sql_base.cc:5928#8 0x0000555558e85626 in open_tables_for_query (thd=0x7fff2c006890, tables=0x7fff2cbee9b8, flags=0) at /mysql/sql/sql_base.cc:6904#9 0x0000555559075720 in Sql_cmd_dml::prepare (this=0x7fff2cbef400, thd=0x7fff2c006890) at /mysql/sql/sql_select.cc:372#10 0x00005555590760bf in Sql_cmd_dml::execute (this=0x7fff2cbef400, thd=0x7fff2c006890) at /mysql/sql/sql_select.cc:527#11 0x0000555558fedc8e in mysql_execute_command (thd=0x7fff2c006890, first_level=true) at /mysql/sql/sql_parse.cc:4794#12 0x0000555558fefe25 in dispatch_sql_command (thd=0x7fff2c006890, parser_state=0x7fffe83f3990, update_userstat=false) at /mysql/sql/sql_parse.cc:5399#13 0x0000555558fe52d3 in dispatch_command (thd=0x7fff2c006890, com_data=0x7fffe83f4b70, command=COM_QUERY) at /mysql/sql/sql_parse.cc:2000#14 0x0000555558fe3643 in do_command (thd=0x7fff2c006890) at /mysql/sql/sql_parse.cc:1448#15 0x000055555920e200 in handle_connection (arg=0x555560a65790) at /mysql/sql/conn_handler/connection_handler_per_thread.cc:307#16 0x000055555ae36375 in pfs_spawn_thread (arg=0x5555608a2e20) at /mysql/storage/perfschema/pfs.cc:2899#17 0x00007ffff77a6609 in start_thread (arg=<optimized out>) at pthread_create.c:477#18 0x00007ffff76cb163 in clone () at ../sysdeps/unix/sysv/linux/x86_64/clone.S:951.2.3.4.5.6.7.8.9.10.11.12.13.14.15.16.17.18.19.20.21.22.23.24.25.26.27.28.29.30.31.32.33.34.35.36.37.38.39.40.41.42.43.44.45.复制#fill_column_from_dd函数里面最重要的是make_field函数，把字段从dd::Column转为table的field然后赋值给TABLE_SHARE。
reg_field = make_field(*col_obj, charset, share, rec_pos, null_pos, null_bit_pos);1.2. 三、知识应用session每次获取表的信息都是在第一次打开表的时候就做好了，下次如果表没有变化就从Table_cache直接获取表信息。现在假设我们要改col4字段的集合值又不想通过alter语句来执行，那就可以直接对dd表进行操作。注意，该操作对生产环境有很大风险，这里只用来进行知识实践，不能用来在生产环境实际操作。站群服务器
把col4的x,y值改为a,b：首先试着插入col4=x的记录，现在还没更改dd表所以插入成功。
复制mysql> insert into t1 values(1,1,aa,1,x,x1);Query OK, 1 row affected (0.03 sec)1.2.接着开始改col4的集合值：
复制mysql> SET SESSION debug=+d,skip_dd_table_access_check;Query OK, 0 rows affected (0.02 sec)mysql> update mysql.columns set default_value_utf8=a ,column_type_utf8=enum(\a\,\b\)) where table_id=383 and name=col4;Query OK, 1 row affected (0.03 sec)Rows matched: 1 Changed: 1 Warnings: 0mysql> select name,ordinal_position,type,default_value_utf8,options,column_type_utf8 from mysql.columns where table_id=383;+-------------+------------------+-----------------------+--------------------+-------------------+------------------+| name | ordinal_position | type | default_value_utf8 | options | column_type_utf8 |+-------------+------------------+-----------------------+--------------------+-------------------+------------------+| col1 | 2 | MYSQL_TYPE_NEWDECIMAL | NULL | interval_count=0; | decimal(65,0) || col2 | 3 | MYSQL_TYPE_VARCHAR | NULL | interval_count=0; | varchar(100) || col3 | 4 | MYSQL_TYPE_LONG | NULL | interval_count=0; | int || col4 | 5 | MYSQL_TYPE_ENUM | a | interval_count=2; | enum(a,b)) |集合值已改
| col5 | 6 | MYSQL_TYPE_SET | NULL | interval_count=2; | set(x1,y1) || DB_ROLL_PTR | 8 | MYSQL_TYPE_LONGLONG | NULL | NULL | || DB_TRX_ID | 7 | MYSQL_TYPE_INT24 | NULL | NULL | || id | 1 | MYSQL_TYPE_LONG | NULL | interval_count=0; | int |+-------------+------------------+-----------------------+--------------------+-------------------+------------------+8 rows in set (0.00 sec)mysql> update mysql.column_type_elements set name=a where column_id=4286 and element_index=1;Query OK, 1 row affected (0.03 sec)Rows matched: 1 Changed: 1 Warnings: 0mysql> update mysql.column_type_elements set name=b where column_id=4286 and element_index=2;Query OK, 1 row affected (0.03 sec)Rows matched: 1 Changed: 1 Warnings: 0mysql> select * from mysql.column_type_elements where column_id=4286;+-----------+---------------+------+| column_id | element_index | name |+-----------+---------------+------+| 4286 | 1 | a |集合值已改
| 4286 | 2 | b |集合值已改
+-----------+---------------+------+2 rows in set (0.00 sec)1.2.3.4.5.6.7.8.9.10.11.12.13.14.15.16.17.18.19.20.21.22.23.24.25.26.27.28.29.30.31.32.33.34.35.36.37.现在再插入一条col4=x的记录发现还是成功的，这是因为t1没有重新从dd表转为TABLE信息，需要重启后再试。
复制mysql> insert into t1 values(2,1,aa,1,x,x1);Query OK, 1 row affected (0.02 sec)1.2.重启数据库，然后登录。再次插入col4=x发现报错了，因为这时候的TABLE信息是重新从dd表转化的。
复制mysql> insert into t1 values(2,1,aa,1,x,x1);ERROR 1265 (01000): Data truncated for column col4 at row 11.2.插入col4=a的记录成功，说明更改成功。
复制mysql> insert into t1 values(3,1,aa,1,a,x1);Query OK, 1 row affected (0.02 sec)1.2.查看建表信息,发现已经成功更改。
复制mysql> show create table t1;+-------+-------------------------+| Table | Create Table |+-------+-------------------------+| t1 | CREATE TABLE `t1` ( `id` int NOT NULL AUTO_INCREMENT, `col1` decimal(65,0) DEFAULT NULL, `col2` varchar(100) DEFAULT NULL, `col3` int DEFAULT NULL, `col4` enum(a,b) DEFAULT a,更改成功
`col5` set(x1,y1) DEFAULT NULL, PRIMARY KEY (`id`)) ENGINE=InnoDB AUTO_INCREMENT=4 DEFAULT CHARSET=utf8mb4 COLLATE=utf8mb4_0900_ai_ci
/*!50100 PARTITION BY HASH (`id`)PARTITIONS 3 */+-------+-------------------------+1.2.3.4.5.6.7.8.9.10.11.12.13.14.15.16. 四、总结实际上更改表结构如果通过alter命令来改流程跟上面也是一样的，也是通过更新dd表来实现表结构的变更，这里只是从更底层来介绍。以上的免费信息发布网操作在实际生产中不能直接操作，风险很大，会影响现有的记录和相关的功能。这里只是作为一个案例来更好的说明dd的工作流程，帮助大家遇到问题知道怎么从底层排查。
