Kill掉MySQLd_Safe进程会影响MySQLd进程？
1、进进程背景
公司内部看到一则问题ill -9 mysqld_safe 进程systemd 检测到 mysqld_safe 进程不存在后，影响重新拉起 mysqld_safe 进程mysqld_safe 进程启动后，进进程发现 mysqld 进程也被重启
期望：启、影响停 mysqld_safe 进程，进进程不会影响 mysqld 进程
2、影响systemd 服务启动
2.1、进进程复现问题
1)、影响查看数据库服务状态
复制[greatsql@greatsql-1 ~]$ sudo systemctl status db-4306 ● db-4306.service - db-4306 Server Loaded: loaded (/usr/lib/systemd/system/db-4306.service; disabled; vendor preset: disabled) Active: active (running) since Wed 2023-07-19 11:15:18 CST; 6h ago Main PID: 14917 (mysqld_safe) CGroup: /system.slice/db-4306.service ├─14917 /bin/sh /greatsql/svr/greatsql/bin/mysqld_safe --defaults-file=/greatsql/conf/greatsql4306.cnf └─16340 /greatsql/svr/greatsql/bin/mysqld --defaults-file=/greatsql/conf/greatsql4306.cnf --basedir=/greatsql/svr/greatsql --datadir=/greatsql/dbdata/data4306/data -... Jul 19 11:15:18 greatsql-1 systemd[1]: Started db-4306 Server. Jul 19 11:15:19 greatsql-1 mysqld_safe[14917]: mysqld_safe Adding /greatsql/svr/GreatSQL-8.0.32-24-Linux-glibc2.17-x86_64/lib/mysql/libjemalloc.so.1 t...or mysqldJul 19 11:15:19 greatsql-1 mysqld_safe[14917]: 2023-07-19T03:15:19.907338Z mysqld_safe Logging to /greatsql/logs/error4306.log. Jul 19 11:15:19 greatsql-1 mysqld_safe[14917]: 2023-07-19T03:15:19.953728Z mysqld_safe Starting mysqld daemon with databases from /greatsql/dbdata/data4306/data Hint: Some lines were ellipsized,进进程 use -l to show in full.1.2.3.4.5.6.7.8.9.10.11.12.2)、kill -9 mysqld_safe 进程，影响并再次查看数据库服务状态
复制[greatsql@greatsql-1 ~]$ kill -9 14917 [greatsql@greatsql-1 ~]$ sudo systemctl status db-4306 ● db-4306.service - db-4306 Server Loaded: loaded (/usr/lib/systemd/system/db-4306.service; disabled; vendor preset: disabled) Active: active (running) since Wed 2023-07-19 18:00:33 CST; 43s ago Main PID: 15195 (mysqld_safe) Tasks: 50 CGroup: /system.slice/db-4306.service ├─15195 /bin/sh /greatsql/svr/greatsql/bin/mysqld_safe --defaults-file=/greatsql/conf/greatsql4306.cnf └─16613 /greatsql/svr/greatsql/bin/mysqld --defaults-file=/greatsql/conf/greatsql4306.cnf --basedir=/greatsql/svr/greatsql --datadir=/greatsql/dbdata/data4306/data -... Jul 19 18:00:33 greatsql-1 systemd[1]: Started db-4306 Server. Jul 19 18:00:34 greatsql-1 mysqld_safe[15195]: mysqld_safe Adding /greatsql/svr/GreatSQL-8.0.32-24-Linux-glibc2.17-x86_64/lib/mysql/libjemalloc.so.1 t...or mysqldJul 19 18:00:34 greatsql-1 mysqld_safe[15195]: 2023-07-19T10:00:34.640240Z mysqld_safe Logging to /greatsql/logs/error4306.log. Jul 19 18:00:34 greatsql-1 mysqld_safe[15195]: 2023-07-19T10:00:34.679333Z mysqld_safe Starting mysqld daemon with databases from /greatsql/dbdata/data4306/data Hint: Some lines were ellipsized,进进程 use -l to show in full.1.2.3.4.5.6.7.8.9.10.11.12.13.14.确实在 kill -9 mysqld_safe 后，重新拉起了 mysqld_safe 和 mysqld 进程(它们的影响 PID 和之前不一样)
3)、查看数据库错误日志
复制2023-07-19T18:00:31.933020+08:00 0 [System] [MY-013172] [Server] Received SHUTDOWN from user <via user signal>. Shutting down mysqld (Version: 8.0.32-24).1.4)、进进程查看 service 文件
复制[greatsql@greatsql-1 ~]$ cat /usr/lib/systemd/system/db-4306.service [Unit] Description=db-4306 Server After=network.target [Install] WantedBy=multi-user.target [Service] User=greatsql Group=greatsql Type=simple ExecStart=/greatsql/svr/greatsql/bin/mysqld_safe --defaults-file=/greatsql/conf/greatsql4306.cnf Restart=on-failure LimitNOFILE=1024000 LimitNPROC=1024000 TimeoutStopSec=15 PrivateTmp=false1.2.3.4.5.6.7.8.9.10.11.12.13.14.15.16.17.18.19.2.2、影响分析原因
1)、进进程查看进程信息
复制[greatsql@greatsql-1 ~]$ ps axj |head -1;ps axj |grep 4306 |grep -v grep PPID PID PGID SID TTY TPGID STAT UID TIME COMMAND 1 15195 15195 15195 ? -1 Ss 986 0:00 /bin/sh /greatsql/svr/greatsql/bin/mysqld_safe --defaults-file=/greatsql/conf/greatsql4306.cnf 15195 16613 15195 15195 ? -1 Sl 986 0:06 /greatsql/svr/greatsql/bin/mysqld --defaults-file=/greatsql/conf/greatsql4306.cnf --basedir=/greatsql/svr/greatsql --datadir=/greatsql/dbdata/data4306/data --plugin-dir=/greatsql/svr/greatsql/lib/plugin --log-error=/greatsql/logs/error4306.log --open-files-limit=65535 --pid-file=/greatsql/dbdata/data4306/data/mysql.pid --socket=/greatsql/dbdata/data4306/data/mysql.sock --port=43061.2.3.4.mysqld_safe：PID(进程 ID)=PGID(进程组 ID)=SID(会话 ID)，说明它是会话首进程，也是该进程组的组长
mysqld_safe 的 PID(进程 ID)=mysqld 的 PPID(父进程 ID)，企商汇说明 mysqld_safe 是 mysqld 的父进程
kill -9 mysqld_safe (会话首进程)，会向该进程组的每一个进程发送 SIGKILL，导致组中的进程被中止
2)、整体流程
mysqld_safe 是会话首进程，kill -9 mysqld_safe，导致组中所有进程被 killsystemd 检测到 mysqld_safe 异常退出，Restart=on-failure 触发重新拉起 mysqld_safemysqld_safe 拉起子进程 mysqld3、mysqld_safe 命令启动
1)、使用 mysqld_safe 启动数据库
复制[greatsql@greatsql-1 ~]$ /greatsql/svr/greatsql/bin/mysqld_safe --defaults-file=/greatsql/conf/greatsql4306.cnf & [1] 18229 [greatsql@greatsql-1 ~]$ mysqld_safe Adding /greatsql/svr/GreatSQL-8.0.32-24-Linux-glibc2.17-x86_64/lib/mysql/libjemalloc.so.1 to LD_PRELOAD for mysqld 2023-07-19T14:20:19.135297Z mysqld_safe Logging to /greatsql/logs/error4306.log. 2023-07-19T14:20:19.173594Z mysqld_safe Starting mysqld daemon with databases from /greatsql/dbdata/data4306/data1.2.3.4.5.2)、查看进程信息
复制[greatsql@greatsql-1 ~]$ ps axj |head -1;ps axj |grep 4306 |grep -v grep PPID PID PGID SID TTY TPGID STAT UID TIME COMMAND 17360 18229 18229 17206 pts/7 17360 S 986 0:00 /bin/sh /greatsql/svr/greatsql/bin/mysqld_safe --defaults-file=/greatsql/conf/greatsql4306.cnf 18229 19658 18229 17206 pts/7 17360 Sl 986 0:02 /greatsql/svr/greatsql/bin/mysqld --defaults-file=/greatsql/conf/greatsql4306.cnf --basedir=/greatsql/svr/greatsql --datadir=/greatsql/dbdata/data4306/data --plugin-dir=/greatsql/svr/greatsql/lib/plugin --log-error=/greatsql/logs/error4306.log --open-files-limit=65535 --pid-file=/greatsql/dbdata/data4306/data/mysql.pid --socket=/greatsql/dbdata/data4306/data/mysql.sock --port=43061.2.3.4.PID≠SID，不是会话首进程PGID≠TPGID，是后台进程组mysqld_safe 的 PID=mysqld 的 PPID，说明 mysqld_safe 是 mysqld 的WordPress模板父进程
3)、kill -9 mysqld_safe 进程，并再次查看进程信息
复制[greatsql@greatsql-1 ~]$ kill -9 18229 [greatsql@greatsql-1 ~]$ ps axj |head -1;ps axj |grep 4306 |grep -v grep PPID PID PGID SID TTY TPGID STAT UID TIME COMMAND 1 19658 18229 17206 pts/7 17360 Sl 986 0:07 /greatsql/svr/greatsql/bin/mysqld --defaults-file=/greatsql/conf/greatsql4306.cnf --basedir=/greatsql/svr/greatsql --datadir=/greatsql/dbdata/data4306/data --plugin-dir=/greatsql/svr/greatsql/lib/plugin --log-error=/greatsql/logs/error4306.log --open-files-limit=65535 --pid-file=/greatsql/dbdata/data4306/data/mysql.pid --socket=/greatsql/dbdata/data4306/data/mysql.sock --port=43061.2.3.4.kill -9 mysqld_safe (非会话首进程)，不影响同组的进程(mysqld)，此时 init 进程会自动领养 mysqld 进程
4)、重新启动 mysqld_safe 进程，并再次查看进程信息
复制[greatsql@greatsql-1 ~]$ /greatsql/svr/greatsql/bin/mysqld_safe --defaults-file=/greatsql/conf/greatsql4306.cnf & [1] 31401 [greatsql@greatsql-1 ~]$ mysqld_safe Adding /greatsql/svr/GreatSQL-8.0.32-24-Linux-glibc2.17-x86_64/lib/mysql/libjemalloc.so.1 to LD_PRELOAD for mysqld 2023-07-19T14:38:42.429733Z mysqld_safe Logging to /greatsql/logs/error4306.log. 2023-07-19T14:38:42.493870Z mysqld_safe A mysqld process already exists [1]+ Exit 1 /greatsql/svr/greatsql/bin/mysqld_safe --defaults-file=/greatsql/conf/greatsql4306.cnf [greatsql@greatsql-1 ~]$ ps axj |head -1;ps axj |grep 4306 |grep -v grep PPID PID PGID SID TTY TPGID STAT UID TIME COMMAND 1 19658 18229 17206 pts/7 17360 Sl 986 0:09 /greatsql/svr/greatsql/bin/mysqld --defaults-file=/greatsql/conf/greatsql4306.cnf --basedir=/greatsql/svr/greatsql --datadir=/greatsql/dbdata/data4306/data --plugin-dir=/greatsql/svr/greatsql/lib/plugin --log-error=/greatsql/logs/error4306.log --open-files-limit=65535 --pid-file=/greatsql/dbdata/data4306/data/mysql.pid --socket=/greatsql/dbdata/data4306/data/mysql.sock --port=43061.2.3.4.5.6.7.8.9.10.11.mysqld_safe 退出，原因是已存在 mysqld 进程
